Features and applications
1. Suitable for mild steel, stainless steel, and special steel.
2. Transmission method: working rollers transmission and supporting rollers transmission. Control methods: common electric pressing down and hydraulic pressing down through AGC system.
3. Equipped with hydraulic bending working rollers which can fast adjust the gibbous degree of rollers to change the distribution of touching pressure between rollers in order to control the plate form.
4. With simple construction, easily maintenance,and less investment.
5. It is equipped with AGC system to get high precision,which is especially suitable for rolling high precision requirements of cold rolled strips.
Components
Entry tension reel(unloading car) → front device → four-high rolling mill → rear device → exit tension reel(unloading car)etc.Uncoiler and head straightening machine could be equipped as per user’s needs.
Technical parameters
|
450 rolling machine |
|
φ175
φ450x450 |
φ140
φ450x450 |
Input thickness |
2.0-3. |
1.0-2.0 |
Product thickness |
0.3-1.0 |
0.2-0.6 |
Stip width |
250-350 |
250-350 |
Transmission |
Working
roll |
support
roll |
Rolling force |
3000 |
3000 |
Pressdown method |
electric |
hydraulic |
electric |
hydraulic |
Speed(m/s) |
1-3 |
4-6 |
1.5-4 |
4-8 |
|
500 rolling machine |
|
φ175
φ500x500 |
φ140
φ500x500 |
Input thickness |
2.0-3.0 |
1.0-2.0 |
Product thickness |
0.3-1.0 |
0.2-0.6 |
Stip width |
300-400 |
300-400 |
Transmission |
Working
roll |
support
roll |
Rolling force |
4000 |
4000 |
Pressdown method |
electric |
hydraulic |
electric |
hydraulic |
Speed(m/s) |
1-3 |
4-6 |
1.5-4 |
4-8 |
|
550 rolling machine |
|
φ180
φ520x550 |
φ140
φ520x550 |
Input thickness |
2.0-3.0 |
1.0-2.0 |
Product thickness |
0.3-1.0 |
0.2-0.6 |
Stip width |
360-450 |
360-450 |
Transmission |
Working
roll |
support
roll |
Rolling force |
5000 |
5000 |
Pressdown method |
electric |
hydraulic |
electric |
hydraulic |
Speed(m/s) |
1-3 |
4-6 |
1.5-4 |
4-8 |
|
650 rolling machine |
|
φ200
φ600x650 |
φ165
φ600x650 |
Input thickness |
2.0-4.0 |
1.0-2.5 |
Product thickness |
0.3-1.5 |
0.2-0.6 |
Stip width |
450-580 |
450-580 |
Transmission |
Working
roll |
support
roll |
Rolling force |
6000 |
6000 |
Pressdown method |
electric |
hydraulic |
electric |
hydraulic |
Speed(m/s) |
1-3 |
4-6 |
1.5-4 |
4-8 |
|
750 rolling machine |
|
φ220
φ650x750 |
φ175
φ650x750 |
Input thickness |
2.0-4.0 |
1.5-3.0 |
Product thickness |
2.0-4.0 |
1.5-3.0 |
Stip width |
550-680 |
550-680 |
Transmission |
Working
roll |
support
roll |
Rolling force |
7000 |
7000 |
Pressdown method |
electric |
hydraulic |
electric |
hydraulic |
Speed(m/s) |
1-3 |
4-6 |
1.5-4 |
4-8 |
|
900 rolling machine |
|
φ230
φ750x900 |
φ180
φ750x900 |
Input thickness |
2.0-2.75 |
1.0-2.75 |
Product thickness |
2.0-2.75 |
1.0-2.75 |
Stip width |
600-800 |
600-800 |
Transmission |
Working
roll |
support
roll |
Rolling force |
8000 |
8000 |
Pressdown method |
electric |
hydraulic |
electric |
hydraulic |
Speed(m/s) |
1-3 |
4-6 |
1.5-4 |
4-8 |
|
